Atomos Shogun 7 HDR Pro Monitor/Recorder/Switcher

SKU: ATOMSHG701
(No reviews yet) Write a Review

$2,459.00

PRODUCT HIGHLIGHTS

  • 7" 1920 x 1280 Touchscreen Display
  • HDR Mode, Dolby Vision Output
  • 1500 cd/m² Brightness
  • DCI 4K up to 60p / 1080p up to 240 fps
  • ProRes Raw / Raw / CinemaDNG / DNxHD

Frequently bought together:

Description

Get your Shogun 7 ready for the road! Purchase a Shogun 7 HDR Monitor and get a FREE Shogun 7 Accessory Kit via redemption. Terms and conditions apply. All claims must be submitted via the Atomos website. Promotional period ends on 15 August, 2020.

Atomos Shogun 7 Overview

The Atomos Shogun 7 is a precision HDR monitor-recorder-switcher designed for the film and video professional. It can be used as either a stand-alone field monitor, recorder and switcher for event, documentary and live in-the-field storytelling; or as a tool for large-scale on-set episodic TV, film and cinema productions where multiple crew members such as focus pullers, grips and cinematographers require a consistent visual reference across the field monitor ecosystem. Shogun 7's portable size lets you monitor, analyze and tag while on set; and check how your content will look in your audience’s home via real-time Dolby Vision output. With Shogun 7 you’re not locked into any format, camera manufacturer or pipeline. It is a completely flexible master recording and production station.

Live multi-cam has never been more portable

Monitor, record and switch between 4 live HD SDI video streams and one program stream for flexible in-the-field directing. Enjoy the freedom of asynchronous switching and gen lock in & out to connect to existing infrastructure. Shogun 7 offers up to HDp60 SDI ISOs x 4 recording. Once you’ve finished capturing your streams, just import the Atomos xml file into your NLE and your timeline populates with all your edits in place. Audio is also taken care of, with each ISO and program record, we insert the mixed analog stereo channels and embed 2 channels of digital audio in each recorded stream. The program stream always records the analog feed and switches between audio inputs for the on-camera audio to match the switched feed.

Single-camera storytelling in 4K, or 2K slow-mo

Capturing in 4K is now becoming a requirement for content streaming providers. With the latest HDMI 2.0v you can capture up to 4Kp60 on any available camera, or via Quad Link, Dual Link or Single Link. If slow motion capture is important to your production, Shogun 7 lets you capture 2K up to 240p. You can tag on-the-fly while recording for direct-to-edit look up in Final Cut Pro X, Adobe Premiere* and Avid Media Composer.

Atomos technology brings the real world to your monitor

Introducing Dynamic AtomHDR technology, designed by Atomos to yield a 1,000,000:1 screen contrast ratio. With Shogun 7 blacks and colors are rich and deep. Images appear to ‘pop’ with added dimensionality and detail. The incredible Atomos screen uses a unique combination of advanced LED and LCD technologies which together offer deeper, better blacks than rival OLED screens, but with the much higher brightness and vivid color performance of top-end LCDs. Objects appear more lifelike than ever, with complex textures and gradations beautifully revealed. In short, Shogun 7 offers the most detailed window into your image, truly changing the way you create visually.

The best HDR just got better

A new 360 zone backlight is combined with our new screen technology and controlled by the Dynamic AtomHDR engine to show millions of shades of brightness and color, yielding jaw-dropping results. It allows Shogun 7 to display 15+ stops of real dynamic range on-screen. The panel is also incredibly accurate, with ultra-wide color and 105% of DCI-P3 covered. For the first time you can enjoy on-screen the same dynamic range, palette of colors and shades that your camera sensor sees.

Record RAW, deliver accurate Dolby Vision HDR

The challenge with HDR production is maintaining the creative intent of the production at the time of shooting vs the finished product that is viewed on devices and TVs. Atomos and Dolby have teamed up to give you Dolby Vision live HDMI out, in real-time, from any SDI or HDMI HDR camera. All courtesy of AtomOS 10.

Simply connect your Dolby Vision capable TV or monitor to your Shogun 7 or Ninja V and magically, automatically, the AtomOS analyses the image, queries the TV, and applies the right color and brightness profiles for the maximum HDR image on the display or TV. This ensures the HDR image always looks – as it was creatively intended by the creator. This is a valuable on-set reference check for the creative director and client.

This function is also available in playback and playout from RAW and Log recorded ProRes RAW, ProRes and DNx rushes for instant time-saving, on-set and in-studio review. Utilise playback functions like slow motion, and insert edit and in and out points to speed up playlist compilation.

View AllClose

SPECS

Display
Panel Type IPS-Type LCD
Display Size 7.2" / 18.3 cm
Screen Resolution 1920 x 1280
Aspect Ratio 16:9
Touchscreen Yes
Maximum Brightness 1500 cd/m2
Dynamic Contrast Ratio 1,000,000:1
Bit Depth / Color Support 8-Bit+FRC (1.07 Billion Colors)
Pixels Per Inch (ppi) 325 ppi
Color Gamut 105% DCI-P3
Real-Time LUT Monitoring SDR
Image Controls Anamorphic De-Squeeze, Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, Screen Markers, Waveform, Zebra, Vectorscope
I/O
Video 1 x HDMI Type A (HDMI 2.0) Input
1 x HDMI Type A (HDMI 2.0) Output
1 x BNC (12G-SDI) Input Shared with 3G-SDI Quad Link
1 x BNC (12G-SDI) Input/Output Shared with 3G-SDI Quad Link
2 x BNC (3G-SDI) Input
1 x BNC (12G-SDI) Output
Embedded Audio HDMI: 8-Channel
HDMI: 2-Channel
SDI: 12-Channel
Audio 1 x 10-Pin LEMO Input
1 x 3.5 mm Headphone Output
Built-In Speaker None
Power 1 x Barrel Input
Other I/O 1 x Genlock (BNC)
1 x LANC (2.5 mm)
Card Slot None
Format Support
Video Format HDMI (8/10-Bit 4:2:2)
DCI 4K: 60/59.94/50/30/29.97/25/24/23.98
UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
DCI 2K: 240/200/120/100/60/59.94/50/30/29.97/25/24/23.98
1080p: 240/120/100/60/59.94/50/30/29.97/25/24/23.98
SDI (8/10-Bit 4:2:2)
DCI 4K: 60/59.94/50/30/29.97/25/24
UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
DCI 2K: 240/200/120/100/60/59.94/50/30/29.97/25/23.98
1080p: 120/100/60/50/30/29.97/25/24/23.98
PC Resolutions 1920 x 1080 at 60 Hz
Video Signal Conversion HDMI to SDI

SDI to HDMI

Recording
Pulldown Conversion 2:2, 3:2
Camera Trigger SDI, HDMI
Encoding Formats 4096 x 2160
ProRes Raw
CinemaDNG
DNxHD
3840 x 2160
ProRes Raw
CinemaDNG
DNxHD
2048 x 1080
ProRes Raw
CinemaDNG
DNxHD
1920 x 1080
ProRes
DNxHD
Maximum Audio Tracks 8
Recording Media 1 x 2.5" SSD (SATA III)
Phantom Power +48 V
Power
DC Input Power 6.2 to 16.8 VDC
Battery Type 2 x L-Series
Mounting
Mounting 2 x 1/4"-20 Female
General
Material of Construction Polycarbonate
Dimensions (W x H x D) 8.43 x 5 x 1.77" / 214 x 127 x 45 mm
Weight 1.56 lb / 709 g
View AllClose

IN THE BOX

Atomos Shogun 7 HDR Pro Monitor/Recorder/Switcher
Master Caddy II
AC Power Supply (12V, 3A)
