Overview
The OM SYSTEM M.Zuiko Digital ED 30mm f/3.5 Macro Lens is a compact macro prime for Micro Four Thirds mirrorless cameras, offering a 60mm equivalent field of view in a lightweight design. Built for close-up photography, product detail work, nature subjects, and everyday creative shooting, it delivers a greater-than-life-size 1.25x maximum magnification for capturing fine textures and small subjects with impressive detail.
With a minimum focusing distance of just 9.5 cm and a minimum working distance of 1.5 cm, this lens is well suited to macro work where precision and subject detail matter. Its optical design uses aspherical, Dual Super Aspherical, and Extra-Low Dispersion Aspherical elements to help reduce aberrations, improve clarity, and maintain accurate colour reproduction across the frame.
Core Features
- 30mm macro prime lens provides a 60mm equivalent focal length for Micro Four Thirds cameras.
- 1.25x maximum magnification supports greater-than-life-size close-up capture.
- Minimum focusing distance of 9.5 cm allows detailed shooting of small subjects.
- Optical construction includes aspherical, DSA, and EDA elements to reduce aberrations and improve sharpness.
- MSC autofocus system delivers quick, quiet, and accurate focusing for stills and video.
- Rounded seven-blade diaphragm helps produce smooth, natural-looking background blur.
Macro Detail in a Compact Form
The lightweight 128 g design makes this lens easy to carry for fieldwork, travel, and handheld close-up shooting. Its compact build pairs well with Micro Four Thirds camera bodies while still delivering strong macro performance for flowers, insects, textures, jewellery, and small product photography.
Quiet AF for Photo and Video
The Movie & Still Compatible autofocus system is designed for fast and quiet operation, making the lens practical for both still photography and movie recording. Manual focus control is also available for fine adjustments when working at very close distances.
Optical
| Focal Length | 30mm |
| 35mm Equivalent Focal Length | 60mm |
| Maximum Aperture | f/3.5 |
| Minimum Aperture | f/22 |
| Lens Format Coverage | Micro Four Thirds |
| Angle of View | 40° |
| Minimum Focus Distance | 9.5 cm |
| Minimum Working Distance | 1.5 cm |
| Macro Reproduction Ratio | 1.25:1 |
| Maximum Magnification | 1.25x |
| Optical Design | 7 Elements in 6 Groups |
| Special Elements | 1 x DSA Element, 1 x Aspherical Element, 1 x EDA Element |
| Aperture Blades | 7, Rounded |
General
| Lens Mount | Micro Four Thirds |
| Focus Type | Autofocus |
| Autofocus Motor | MSC High-Speed Imager AF System |
| Manual Focus | Yes |
| Image Stabilization | No |
| Filter Size | 46 mm Front |
Physical
| Dimensions | 6.0 x 5.7 cm |
| Weight | 128 g |
What's Included
- OM SYSTEM M.Zuiko Digital ED 30mm f/3.5 Macro Lens
- Front Lens Cap
- Rear Lens Cap
- Barcode: 88756
- UPC Barcode: 4545350054052
- Supplier Code: OLL2048
