Overview
The FeelWorld T6 6" 4K HDMI Touchscreen HD Monitor features a 1920 x 1080 resolution display with a maximum brightness of 450 cd/m². It supports HDMI input signals with resolutions up to DCI/UHD 4K60 and provides an HDMI output for connecting to wireless transmitters, larger on-set monitors, and other devices.
Durable Design
The durable monitor features an aluminum housing and a series of camera auxiliary functions to meet your creative needs anytime, anywhere.
HDR Compatibility
When HDR is activated, the display reproduces a greater dynamic range of luminosity, allowing lighter and darker details to be displayed more clearly using built-in HLG1, HLG2, and HLG3.
HDMI Input and Output
Equipped with HDMI 2.0 input and output, this monitor supports resolutions up to DCI 4K at 60 fps, compatible with DSLR and mirrorless cameras. A 3.5 mm headphone jack allows monitoring of embedded HDMI audio.
Menu User Switching
The T6 provides four different groups for saving menu settings. Four buttons on the monitor top provide quick access to favorite settings. You can select between groups 1, 2, 3, or 4 for different shooting scenarios.
Integrated Image Tools
A large set of software features includes waveform, vectorscope, histogram, and anamorphic mode, accessible via the touchscreen. The menu system provides live views of most settings, including log profiles and LUTs.
Custom 3D LUTs
The monitor supports 3D-LUTs to quickly adjust color tones. It features four built-in DE-log LUTs and supports up to 32 custom .cube files via USB-A to USB-C connection.
Power Input Options
Multiple power options include:
- 12 VDC input for optional power supply
- 5 V USB-C port for power banks, adapters, or computer port
- Battery slot for Sony L-series type battery
DC Power Output
The T6 provides 8 V DC output to power cameras via optional adapter cable, extending runtime while providing a usable display.
Mounting Threads
Two 1/4"-20 mounting threads on the bottom and right side allow rig or camera cage mounting. The included shoe mount adapter supports 180° tilt and 360° rotation.
Sun Hood
A sunshade is provided to prevent glare or reflections, snapping onto the front of the monitor without tools.
Specifications
| Display Size | 15.2 cm |
| Native Resolution | 1920 x 1080 |
| Touchscreen | Yes |
| HDR Support | Yes |
| Video I/O | 1x HDMI 2.0 Input, 1x HDMI 2.0 Output |
| Media/Memory Card Slot | No |
| Battery | 1x L-Series Mount on Fixed Plate |
| Power Consumption | 9 W |
Display
| Panel Type | IPS-Type LCD |
| Aspect Ratio | 16:9 |
| Viewing Angle | 160° Horizontal / 160° Vertical |
| Maximum Brightness | 450 cd/m² |
| Contrast Ratio | 1000:1 |
| Color Support | 16.7 Million Colors (8-Bit) |
| LUT Support | Yes |
| Image Controls | Anamorphic De-Squeeze, Check Field, Color Temperature Selection, Custom Aspect Ratios, False Color, Focus Assist, Histogram, Image Flip, Image Freeze, Image Rotate, Marker Color, Overscan, Screen Markers, Underscan, Vectorscope, Waveform, Zebra |
Inputs / Outputs
| Video I/O | 1x HDMI 2.0 Input, 1x HDMI 2.0 Output |
| Audio I/O | 1x 3.5 mm Headphone Output |
| Power I/O | 1x USB-C (5 VDC) Input, 1x Barrel (12 VDC) Input, 1x Barrel (8 VDC) Output |
Wireless
| Wi-Fi | No |
| Bluetooth | No |
| Mobile App Compatible | No |
Power
| Input Power | 12 VDC at 1 A, 5 VDC at 2 A |
| Battery | 1x L-Series Mount on Fixed Plate |
| Power Consumption | 9 W |
Mounting
| Tripod/Accessory Mounting | Bottom/Right, 1x Anti-Twist 1/4"-20 Female |
General
| Operating Conditions | -20 to 50°C |
| Storage Conditions | -30 to 60°C |
| Dimensions | 151.8 x 92.8 x 17.1 mm |
| Weight | 184 g |
What's Included
- FeelWorld T6 6" 4K HDMI Touchscreen HD Monitor with Aluminum Housing
- Micro-HDMI Cable (50 cm)
- Tilting Shoe Mount
- Hex Key
- USB-A to USB-C Cable
- Sunshade
- Zippered Case
- Barcode: 84707
- UPC Barcode: 6971863819129
- Supplier Code: T6
