Nikon ZR 6K Cinema Camera

SKU:
VOA180AA

Key Features

  • Fusion of RED + Nikon Cinema Technology
  • 6K Full-Frame Z-Mount Cinema Camera
  • REDCODE RAW R3D + N-RAW Recording
  • ProRes RAW/HQ, H.265/H.264 Codecs
$3,999.00

Or buy now, pay later with:

zip after qcard-payment credit-capable-payment
Adding to cart… The item has been added

Overview

By combining RED color science and Nikon engineering, the Nikon ZR 6K Cinema Camera is a first-of-its-kind powerhouse designed to capture stunning cinematic images in one compact body. This tiny Z-mount cinema camera allows you to use a variety of lenses, and internal stabilization provides a smooth, steady image with 15+ stops of dynamic range. Features include 32-bit float audio, advanced autofocus, dual-base ISO, and up to 6K60 video capture in REDCODE, Z-RAW, or ProRes RAW.

Color Science

Nikon + RED Color Science

The partnership of Nikon and RED provides a wide range of compatibility with production workflows, offering REDCODE RAW R3D recording format along with Nikon's N-RAW, ProRes RAW HQ/422 HQ, and the high-quality compressed H.264 and H.265 codecs. REDCODE RAW (R3D NE) unlocks the same color space (REDWideGamutRGB) and Log curve (Log3G10) as RED cameras.

The camera captures resolutions up to 6K60, 4K120, and even 1080p240 for high frame rate, slow-motion recording.

Audio Features

Audio Capture

The ZR captures high-quality audio using dynamic 32-bit float and 24-bit recording, and it supports standard 48 kHz linear PCM for full video compatibility.

It features built-in configurable mics, a line input that provides the ability to record with an external microphone, and the camera's digital accessory shoe that can utilize mics such as the ME-D10 shotgun or H2315 shoe mic attachment. A headphone jack allows you to monitor the audio.

Recording and Output

Recording and Output

The camera records to a CFexpress Type B card slot that is accessed through the battery door to keep the camera compact and mobile while a microSD card slot is available for proxy recording. There is also a micro-HDMI output that allows you to output to a display or recording device.

Autofocus

Advanced Autofocus

Nikon's advanced autofocus feature is powered by deep learning, providing up to 9-subject detection autofocus with automatic tracking of people, animals, and vehicles.

Display

Large, Bright Display

The built-in 4" variable-angle touchscreen display features a DCI-P3 color gamut, 1000 cd/m² brightness, and a 3.07 million dot resolution for viewing your controls and footage with ease.

The display can automatically flip when you change from horizontal to vertical mode.

Customization

Custom LUTs

The camera provides the ability for the operator to load up to 10 LUTs into the camera for real-time preview on its display.

Lens Compatibility

Lenses and Image Stabilization

The standard Z lens mount allows you to utilize the entire line of NIKKOR Z lenses and a wide range of third-party lenses and lens mount adapters.

The ZR provides integrated image stabilization with any prime or zoom lens at up to 7.5 stops to provide smooth, steady image capture.

ISO Sensitivity

Dual-Base ISO

The ZR provides extended ISO sensitivity to the base ISO with its dual-base ISO, providing 800/6400 for both Log3G10 and N-Log profiles.

Connectivity

Frame.io Integration

The camera's companion app allows you to streamline your workflow by connecting the camera to your phone and utilizing the optional Frame.io cloud service, making asset control, post production, and live streaming easy.

Power Options

Power Options

The camera is powered via one EN-EL15c battery in its battery slot, or it can be powered via USB-C using an external power source such as an optional power supply or power bank.

Design

Ultracompact Design

This tiny camera is the size of a small mirrorless camera but packs in cinema camera technology.

Take the camera into the field, mount it onto a vehicle, stabilize it on a gimbal, or perform steadycam, drone, or POV shots - it's lightweight enough to perform just about anywhere.

Specifications

Lens Mount Nikon Z
Image Sensor 35.9 x 23.9 mm (Full-Frame) CMOS
Sensor Resolution Effective: 24.5 Megapixel
Image Stabilization Sensor-Shift, 5-Axis
ISO/Gain Sensitivity Native: 800, Native: 6400
Internal Recording ProRes RAW HQ/Raw/REDCODE RAW, UHD 6K (6000 x 3000) up to 60.00 fps, DCI 4K (4096 x 2160) up to 120 fps, UHD 4K (3840 x 2160) up to 120 fps, 1920 x 1080p up to 240 fps
Media/Memory Card Slot Single Slot: CFexpress Type A
Video I/O 1x Micro-HDMI Output
Mobile App Compatible Yes: Android & iOS
Battery Type Nikon EN-EL15c
Lens Communication Yes: with Autofocus Support
Built-In ND Filter No
Built-In CC Filter No
Internal Filter Holder No
Capture Type Stills & Video
Shutter Type Electronic Rolling Shutter
Advertised Dynamic Range 15 Stops
Focus Modes Automatic
Fast-/Slow-Motion Support Yes
Gamma Curve Nikon N-Log, REDWideGamutRGB
Built-In Microphone Stereo
Internal Storage No
Audio I/O 1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input, 1x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O 1x USB-C Input
Global Positioning (GPS, GLONASS, etc.) No
Display Type Primary Monitor: Articulating 4" Touchscreen LCD
Shoe Mount 1x Intelligent Hot Shoe

What's Included

  • Nikon ZR 6K Cinema Camera
  • Nikon EN-EL15c Lithium-Ion Battery (2280mAh)
  • Nikon UC-E25 USB Cable
  • Nikon BS-D1 Digital Accessory Shoe Cover
  • Nikon BF-N1 Body Cap
  • Nikon AN-DC26 Camera Strap
  • Barcode: 85610
  • UPC Barcode: 4960759919618
  • Supplier Code: VOA180AA
