Deity SRD-Mini Portable 4-Channel Antenna Distribution System (470 MHz to 1 GHz) + BONUS Gift

SKU:
DTR0289D51

Key Feature

  • Ultra-Slim RF Distro
  • Supports Passive and Active Antennas
  • 2-to-8 Active Splitter
  • 1 A In x 4 A Outs / 1 B In x 4 B Outs
  • Supplies Power to External Antenna
  • Power: USB, 4-Pin Hirose, RPS Interface
  • Lightweight CNC Aluminum Construction
$1,149.00

Or buy now, pay later with:

zip after qcard-payment credit-capable-payment
Adding to cart… The item has been added

Deity Bonus Gift Promotion

Promotion overview:

  • Purchase a PR-2 Stereo Pocket Recorder and receive a BONUS AA battery
  • Purchase a SRD Mini and receive a BONUS BF1 UHF Antenna
  • Purchase a TC-SL1 and receive a BONUS Screen Protecter and NP-F550 Rechargeable
  • Purchase a 140W GaN Pro Charger and receive a BONUS C24 UBS C-C Cable
  • Purchase a Microphone S-Mic 3 and receive a BONUS W01 Windshield
  • Purchase a Microphone S-Mic 3S and receive a BONUS W02 Windshield



Purchase period:
15th May until Sunday 31st July 2025.



Redemption Page:
Bonus gift will be given to the customer at point-of-purchase via in-store or online.



-----------------







"

Deity Microphones SRD-Mini Overview

Simplify the management of wireless microphone signals in demanding field conditions with the Deity Microphones SRD-Mini, an ultra-slim, portable 4-channel antenna-distribution system designed specifically for location sound mixers. This RF distro is equipped with two main ins and four outs (A and B), for a 2-to-8 split.


Supporting both passive and active antennas, the SRD-Mini features an active splitter that compensates for gain loss, ensuring that your RF signals remain strong and consistent. The unit also supplies power to external antenna circuitry. Each side of the distro (A / B) can have it's external power toggled on or off independently. The SRD-Mini is made of CNC aluminum and is ultralightweight. Its slim and ergonomic design makes it easy to place it wherever you need to in your sound bag.

Industry Standard Connectors

  • The SRD-Mini utilizes standard connectors, ensuring compatibility with a wide range of equipment.
  • Two 50-ohm BNC ports act as the A/B inputs while eight 50-ohm SMA outputs split the incoming signal ( 1 A x 4 A / 1 B x 4 B).

Wide Frequency Range

  • The SRD-Mini operates in the 470 MHz to 1 GHz range, allowing it to operate anywhere in the world and with nearly any UHF wireless microphone system you may already own.

Multiple Power Options

  • The SRD-Mini has traditional power inputs like a 12-16.8 VDC 4-pin Hirose-compatible connector and a 5 VDC USB-C connector.
  • For a cable-less power solution, the unit can also be powered from the SPD-Mini power distributor (available separately) via its pogo pins.

Deity Microphones SRD-Mini Specifications

Inputs / Outputs

USB I/O 1 x USB-C Female Input
RF Input 2 x BNC Connectors
RF Output 8 x SMA Connectors
Impedance Input: 50 Ohms
Output: 50 Ohms
Gain +3 to +9 dB
Port Isolation >20 dB (Minimum)
Noise Factor <1.5 dB

Wireless

Wireless UHF
*Built-In
Frequency Range 470 MHz to 1 GHz
Gain +3 to +9 dB
Port Isolation >20 dB (Minimum)
Noise Factor <1.5 dB

Power

Power Source USB, DC Input, Proprietary Interface
DC Input Power 5 to 16.8 VDC at 160 mA

Physical

Color Black
Material of Construction CNC Aluminum
Dimensions 115.5 x 78 x 20.8 mm
Weight 185.5 g

What's in the box

  • 1 x Deity SRD-Mini Portable 4-Channel Antenna Distribution System (470 MHz to 1 GHz)
  • Barcode: 74469
  • UPC Barcode: 6971842186099
  • Supplier Code: DTR0289D51
