Overview
The OM SYSTEM Fisheye Body Cap 9mm f/8 Lens is an ultra-compact fisheye lens designed for Micro Four Thirds mirrorless cameras. Offering an 18mm full-frame equivalent focal length and an expansive 140° angle of view, this unique lens delivers dramatic fisheye perspectives while maintaining an incredibly slim profile. Measuring just 12.8mm thick, it functions much like a body cap, making it an ideal carry-anywhere lens for travel, street photography, creative landscapes, and experimental image-making.
Despite its miniature size, the lens incorporates two aspherical elements that help improve sharpness and control distortion across the frame. A simple manual focus lever allows quick switching between Deep Focus and Close-Up positions, enabling photographers to capture everything from broad scenes to subjects as close as 20cm away. Lightweight, portable, and fun to use, this lens offers a creative alternative to conventional wide-angle optics.
Core Features
- 9mm fisheye design provides an 18mm full-frame equivalent focal length with an expansive 140° angle of view.
- Ultra-slim body cap construction measures just 12.8mm thick for exceptional portability.
- Two aspherical elements help improve sharpness and minimise optical aberrations.
- Manual focus lever enables quick switching between Deep Focus and Close-Up shooting positions.
- Close focusing capability down to 20cm allows for creative wide-angle close-up compositions.
Always Ready to Carry
Its body cap-style design adds virtually no bulk to your camera, making it easy to keep mounted or carry as a creative backup lens wherever you go.
Distinctive Fisheye Perspective
The 140° field of view captures dramatic curved perspectives and expansive scenes, making it ideal for travel photography, architecture, action shots, and creative visual storytelling.
Optical
| Focal Length | 9mm (35mm Equivalent: 18mm) |
| Maximum Aperture | f/8 |
| Minimum Aperture | f/8 |
| Lens Format Coverage | Micro Four Thirds |
| Angle of View | 140° |
| Minimum Focus Distance | 20 cm |
| Maximum Magnification | 0.05x |
| Macro Reproduction Ratio | 1:20 |
| Optical Design | 5 Elements in 4 Groups |
| Aperture/Iris Blades | 1, Rounded |
General
| Lens Mount | Micro Four Thirds |
| Focus Type | Manual Focus |
| Image Stabilization | No |
Physical
| Dimensions | Diameter: 56 mm, Length: 12.8 mm |
| Weight | 30 g |
What's Included
- OM SYSTEM Fisheye Body Cap 9mm f/8 Lens
- Rear Lens Cap
- Barcode: 25928
- UPC Barcode: 050332193918
- Supplier Code: OLL2006
