Amaran F22x Bi-Color Flexible LED Mat (V-Mount, 2 x 2') (By Aputure)

SKU:
AP20235A13
(No reviews yet) Write a Review
Key Features
  • For Studio & Film/TV Production
  • Output: 6960 Lux at 3.3' (5600K)
  • 2500-7500K; HSI Color Control
  • 2x2'; AC/DC Operation
$1,104.00

Or buy now, pay later with:

zip after qcard-payment credit-capable-payment
Adding to cart… The item has been added

amaran F22X Overview

The F22x Bi-Color LED Flexible Mat from amaran is powerful, versatile, and flexible bi-color LED mat that measures 2x2'. It offers outstanding light output and color rendering suitable for a variety of users, from filmmakers to videographers, content creators, and still photographers. Providing 200W of power, this ultralight fixture's high-output bi-color chipset can be tuned from 2500K to 7500K, and features nine customizable lighting FX. It has stellar CRI and TLCI scores of 95+ and 98+, and stepless dimming from 0 to 100%. An included folding X-frame stretches the mat to a rigid panel that can be attached directly to a C-stand grip head using the straight Baby Pin adapter, or onto any standard light stand with the included right angle Baby Pin and tilting stand mount. The included foldable softbox has two strengths of diffusion, and a fabric grid that uses using an integrated hook-and-loop fabric to instantly turn this flexible mat into an ultrathin soft light that will add beautifully controlled soft light to a scene.

The control box is a multi-voltage AC power supply that also features a V-Mount battery plate for use with compatible 14.4V, 26V, or 28.8V batteries. Full output can be achieved when using the AC power supply, using batteries allows the F22x to be used at either half-power or full-power, depending on battery strength.

The free Sidus Link app makes it possible to utilize tools unique to the Aputure and amaran ecosystems, such as Source Match, Color Picker, and Custom FX. The F22x can also be controlled using DMX with a separately available USB-C to 5-Pin DMX512 in & out adapter cable, adding professional-level control to an individual unit or groups of lights. The amaran F22x is ideal for videographers who need a versatile and literally flexible lighting solution. The bi-color flexible panel gives users unmatched strength and control over a wide, expanded CCT range to match a variety of white light environments.

  • 200W output
  • 2x2' bi-color flexible LED mat
  • Color temperature from 2500-7500K
  • CRI: 95+, TLCI: 98+, CQS: 96+
  • SSI (Tungsten): 81+, SSI (D56): 72+
  • Stepless dimming from 0 to 100%
  • Ultralight LED mat
  • Sidus Link App control for smartphones & tablets
  • DMX control with USB-C to 5-Pin DMX512 in & out adapter cable, separately available
  • 9 Built-in lighting FX including paparazzi, lightning, TV, candle, fire, strobe, explosion, faulty bulb, pulsing
  • Easy-mounting multi-voltage AC power supply with included V-Mount battery mount
  • Multiple DC power solutions: 14.4V/26/28.8V/48V (3-Pin XLR)
  • Soft carrying case

Amaran F22X Specs

Light Fixture
Item Type 1 x LED Flexible Light
Included Light Modifier 1 x Softbox with Removable Grid
Included Storage Case 1 x Case
Lumens Not Specified by Manufacturer
Photometrics 3200K:
562 fc / 6050 Lux at 3.3' / 1 m
5600K:
646 fc / 6960 Lux at 3.3' / 1 m
Color Temperature 2500 to 7500K
Color Modes Daylight, Tungsten
Color Accuracy Standard CRI 95 at 5600K
TLCI 98 at 5600K
CQS 96 at 5600K
SSI 81 at 5600K
Cooling System Passive
Dimming Yes, Includes Hardware
0 to 100% (Continuous)
Expected Lamp Life 50,000 Hours
Front Accessory Mount Proprietary
Connectivity
Wireless Remote Control Type Bluetooth
Mobile App Compatible Yes: Android & iOS
App Name: Sidus Link
*As of March, 2022: Check with manufacturer for the most up-to-date compatibility
Wireless Range 262.5' / 80 m (Bluetooth)
Power & I/O
Power Source AC to DC Adapter (Included)
Battery (Not Included)
Inputs/Outputs 1 x USB-C DMX Input
*Adapter Required (Not Included)

1 x XLR 3-Pin Power Input
1 x Proprietary Power Output
Battery Plate Type 1 x V-Mount (Built-In)
Battery 1 x Rechargeable, 14.4 to 28.8 VDC (Not Included)
AC Input Power 100 to 240 VAC, 50 / 60 Hz
DC Input Power 48 VDC at 2.5 A
Included Adapter / Cable 1 x Edison Plug to XLR 3-Pin AC to DC Adapter (48 VDC)
Inline Switch No
Power Pass-Thru No
Power Consumption 240 W
Mounting
Fixture Mounting 1 x 5/8" Receiver
Included Adapter 1 x Non-Swivel Mount: 5/8" Receiver to 5/8" Receiver
2 x Non-Swivel Mount: 5/8" Stud to 5/8" Stud
Environmental
Environmental Protection None
Operating Temperature 14 to 104°F / -10 to 40°C (Recommended)
General
Display OLED
Certifications CE, FCC, RoHS, cTUVus
*as per Manufacturer
Materials Plastic (Housing)
Dimensions 23.6 x 23.6 x 0.2" / 60 x 60 x 0.5 cm (Fixture)
Weight 1.5 lb / 0.7 kg (Power Supply/Controller)
1.8 lb / 0.8 kg (Fixture)
Packaging Info
Package Weight 17.79 lb
Box Dimensions (LxWxH) 26.9 x 15.6 x 5.3"

In the Box

  • amaran F22x 2x2 Bi-Color LED Flexible Mat (V-Mount)
  • F22x Control Box with V-Mount Plate
  • F22 9.8" Head Extension Cable
  • F22 Support Bracket
  • Flex Light Right Angle Baby Pin Adapter
  • Flex Light Straight Baby Pin Adapter
  • Tilting Stand Mount
  • F22 Softbox Frame
  • F22 Diffusion Cloth 1 (1/2 Grid Cloth)
  • F22 Diffusion Cloth 2 (2.5 Stop)
  • F22 Light Control Grid
  • Multi-Voltage AC Power Supply
  • AC Power Cable
  • Carrying Case
  • Barcode: 58336
  • UPC Barcode: 6971842183319
  • Supplier Code: AP20235A13
